SSR DC Output Motor Control Manufacturers 3.3 V Solid State Relay

Basic Info

Model NO.	GSR
Theory	Solid State Relay
Usage	SSR
Phase	1/3
Electricity Type	AC DC
Number of Pole	1-4
Load	Medium Power Relay
Protective Characteristics	Enclosed Rlay
Action Principle	Electronic Type
Size	Miniature
Type	Non-Electric Parameter Relay
MOQ	20
Transport Package	Standard Transport Box
Specification	10-200DA
Trademark	GEYA
Origin	Zhe

Product Description

GSR1-1-10DA	Single phase
GSR1-1-25DA
GSR1-1-40DA
GSR1-1-60DA
GSR1-1-80DA
GSR1-1-100DA
GSR1-1-120DA
GSR1-1-10AA
GSR1-1-25AA
GSR1-1-40AA
GSR1-1-60AA
GSR1-1-80AA
GSR1-1-100AA
GSR1-1-10DD
GSR1-1-25DD
GSR1-1-40DD
GSR1-1-60DD
GSR1-1-80DD
GSR1-1-100DD
GSR1-3-10DA	Three phase
GSR1-3-25DA
GSR1-3-40DA
GSR1-3-60DA
GSR1-3-80DA
GSR1-3-100DA
GSR1-3-120DA
GSR1-3-150DA
GSR1-3-200DA
GSR1-3-10AA
GSR1-3-25AA
GSR1-3-40AA
GSR1-3-60AA
GSR1-3-80AA
GSR1-3-100AA
GSR1-3-120AA
GSR1-3-150AA
GSR1-3-200AA
GSR1-3-10DD
GSR1-3-25DD
GSR1-3-40DD
GSR1-3-60DD
GSR1-3-80DD
GSR1-3-100DD
GSR1-3-120DD
GSR1-3-150DD
GSR1-3-200DD
GSR2-1-10DA	SSR with Radiator
GSR2-1-25DA
GSR2-1-40DA
GSR2-1-60DA
GSR2-1-80DA
GSR2-1-100DA
GSR2-1-120DA
GSR2-1-10AA
GSR2-1-25AA
GSR2-1-40AA
GSR2-1-60AA
GSR2-1-80AA
GSR2-1-100AA
GSR2-1-120AA
GSR2-1-10DD
GSR2-1-25DD
GSR2-1-40DD
GSR2-1-60DD
GSR2-1-80DD
GSR2-1-100DD
GSR2-1-120DD

Single phaseinput parameter
Control voltage range	3-32VDC
Minimum control current	5mA
Maximum control current	15mA
Ensure that the voltage is turned on	3.5VDC
Ensure shutdown voltage	1.5VDC
Output parameters
Output voltage range	24-480VAC
Specification / maximum load current	10A	25A	40A	60A	80A	100A	120A
Peak voltage	800VAC			1200VAC
insulation resistance	1000MΩ/500VDC
Leakage current under off state	≤8mArms			≤2mArms
Saturation pressure drop in on state	≤1.5V
On-off reaction delay	≤10ms
General characteristics
size	57.4L×44.8W×28H
weight	100g
Insulation and withstand voltage between input and output	2500Vrms
Insulation and withstand voltage between input and output and housing	4000Vrms
ambient temperature	-20°~75°C
Installation mode	Bolt fixing
Relevant certification	CE

Three phaseinput parameter
Control voltage range	70-280VDC
Minimum control current	5mA
Maximum control current	10mA
Ensure that the voltage is turned on	90VAC
Ensure shutdown voltage	50VAC
Output parameters
Output voltage range	24-480VAC
Specification / maximum load current	10A	25A	40A	60A	80A	100A	120A	200A
Peak voltage	800VAC			1200VAC
insulation resistance	1000MΩ/500VDC
Leakage current under off state	≤8mArms			≤2mArms
Saturation pressure drop in on state	≤1.5V
On-off reaction delay	≤10ms
General characteristics
size	105L×74W×33H
weight	500g
Insulation and withstand voltage between input and output	2500Vrms
Insulation and withstand voltage between input and output and housing	4000Vrms
ambient temperature	-20°~75°C
Installation mode	Bolt fixing
Relevant certification	CE

SSR with Radiator

brand	GEYA
Product name	GSR solid state relay
control mode	DC controlled AC
load current	10A,25A,40A,60A,80A,100A
Load voltage	24-480VAC
control voltage	3-32VDC
Control current	DC5-25MA
Power off time	≤10mS
Dielectric Strength	2500VAC
Work instructions	LED
ambient temperature	- 30~+75°C
Overall dimension	45 * 31 * 58mm (opening 45mm)
