61f-G Electrical Multi-Function Liquid Level Control Floatless Relay with CE

Basic Info

Model NO.	61F-G
Electricity Type	Ac
Number of Pole	1
Load	Weak Power Relay
Protective Characteristics	Sealed Relay
Action Principle	Electronic Type
Size	Miniature
Type	Electric Parameter Relay
Brand	Winston
Dimensions(mm)	79.5h *135W * 127D
Weight	380g
Ambient Huminity	48~85%Rh
Consumed Power	3.2va
Connection Diagrams	35e
Transport Package	Export Standard Carton Box or ODM
Specification	CE
Trademark	Winston/OEM/Neutral
Origin	China, Zhejiang, Wenzhou
HS Code	8536411000
Production Capacity	10000PCS/Week

Packaging & Delivery

Package size per unit product 10.00cm * 16.00cm * 15.00cm Gross weight per unit product 1.000kg

Product Description

Product Description

1. Easy maintenance with building-block Relay Units.
2.Easy identification of operating status with LED operation
indicator.
3.Lineup includes models for tropical regions and for high
temperatures. Achieve stable detection even in hightemperature environments.



CLASSIFICATION		FLOATLESS RELAY
MODEL		61F-G
DIMENSIONS(mm)		79.5H*135W*127D
SOCKET TYPE		--
SENSING MODE	GENERAL	61F-G
	HIGH SENSING	--
	LONG DISTANCE	--
	LOW DENSITY	--
	TWO LINES	--
RATED VOLYAGE		AC:110V,220V,240V,50/60Hz
INDICATOR OPERATING		Two LED's use for two status
OPERATE VOLYAGE		85~110% of rated voltage
SECOND VOLTAGE		8VAC(except high sensing 24VAC)
OPERATE RESISTANCE		4K Ωmin.(GENERAL)
RELEASE RESISTANCE		15K Ωmin.(GENERAL)
RESPONSE TIME		Operate:80msec max, Release:160 msec max
CONTACTRATING		5A, 250VAC(RESISTIVELOAD)
LENGTH OF CABLE		1Km max.(GENERAL)
LIFE	MECHANICAL	5*106 times min
	ELECTRICAL	105 times min
INSULATION RESISTANCE		100MΩ(DC 500V) min
DIELECTRIC STRENGTH		1500VAC, 50/60Hz, for 1 minute
CONSUMED POWER		3.2VA
AMBIENT TEMPERATURE		-10°c~+55°c
AMBIENT HUMIDITY		45~85%RH
WEIGHT		750g
